1U short depth 4-bay Compact Server Chassis
Model：U1000N4000
• Dimension : 481mm x 755.7mm x 1U
• M/B : Micro ATX(9.6" X 9.6") X2 sets
• Drive Bays : 3.5” HDD x 4
• PSU Type : 1U Flex PSU x 2
Welcome any customized modification
Add to inquiry
• M/B : Micro ATX(9.6" X 9.6") X2 sets
• Drive Bays : 3.5” HDD x 4
• PSU Type : 1U Flex PSU x 2
Welcome any customized modification
Features
► Unique Outlook Design
► Reliable Safety Device
► Super System Expansibility
► Easy Assembly & Service
► Effective cooling design to tackle thermal issues
U-Rack's 1U chassis redefines density and performance in a compact 481mm x 755.7mm x 1U form factor. This powerhouse accommodates two Micro ATX motherboards and four 3.5” HDDs, offering exceptional expandability for diverse configurations. Dual 1U Flex PSUs ensure reliable power redundancy. The unique design prioritizes both aesthetics and functionality, with an effective cooling system to tackle thermal challenges. Reliable safety devices safeguard your hardware, while the intuitive layout simplifies assembly and service. Experience unparalleled versatility and performance with U-Rack's 1U chassis - the perfect choice for your demanding server applications.
Specification
| Model NO. | U1000N4000 |
| Standard | EIA-RS310D |
| Dimension | 481mm x 755.7mm x 1U |
| (W x D x H) | (18.9" x 29.75" x 1.7") |
| Material | SGCC / 1.2mm thickness |
| M/B | Micro ATX(9.6" X 9.6") X2 sets |
| Drive bays | 3.5” HDD x 4 |
| Coolings | 9 x 4cm ball bearing |
| Indicators | (Power, HDD LED) X2 sets |
| Controls | (Power on/off, system reset, USB port) X2 sets |
| Slots | N/A |
| Power Supply | 1U Flex PSU x 2 |
